Just as SAPTAK signifies the entire Indian classical music scale, our amplifiers are designed for accurate and perfect reproduction of the entire music scale.
Class A Dual Mono Integrated Amplifier (Signature)
Class A Dual Mono Integrated Amplifier
- Dual Mono
- 4 Source Selection
- High Current Capable Dual Rail Linear PSU
- Cornell Dubilier AND Nichicon MUSE Capacitors
- High end cabling, Mogami and Lapp Kabel Germany
| General Description | Class A Dual Mono Integrated Amplifier |
|---|---|
| OUTPUT POWER | 20.6 watts @ 8 Ohms / 38 watts @ 4 Ohms per channel |
| POWER AMPLIFIER CLASSIFICATION | Class A |
| INPUTS | RCA unbalanced |
| INPUT IMPEDANCE | Unbalanced 100 kOhm |
| FREQUENCY RESPONSE | Less than +/- 0.2 dB deviation 10 Hz - 50 kHz |
| DISTORTION | Less than 0.054% at rated power 8 ohms load |
| Input Sensitivity (Full Power) | 2 V |
| DAMPING FACTOR | More than 100 |
| POWER SUPPLY | 300 + 300 VA dual mono; 88,000 + 88,000 uF capacitors |
| POWER CONSUMPTION | 190 W in standby switched on |
| ADDITIONAL FEATURES | Speaker soft start & shutdown, short circuit and DC protection |
| HEIGHT (Including rubber feet) | 6.9’’ (17.5 cm) |
| WIDTH | 16.9” (43.0 cm) |
| DEPTH | 16” (40.6 cm) |
| WEIGHT | 18 Kg (40 lbs) |
DISCLAIMER : All products, product specifications and data are subject to change to improve reliability, function or design, without notice
