Just as SAPTAK signifies the entire Indian classical music scale, our amplifiers are designed for accurate and perfect reproduction of the entire music scale
Integrated Stereo Amplifier (Gold)
Integrated Stereo Amplifier
- Warm and natural sound
- 2 dB dynamic head room
- Premium grade construction
- Extremely low distortion levels
- Aluminium brushed finished front panel
| General Description | Integrated Stereo Amplifier |
|---|---|
| OUTPUT POWER | More than 120 + 120 watts @ 8 Ohms / 200 + 200 watts @4 Ohms |
| POWER AMPLIFIER CLASSIFICATION | Class AB, Integrated pre-amplifier and tone control (Source direct, LF lift, Mid lift, HF lift and combination), Muting option, Tone control: 1.5 dB LF lift, 1.5 dB Mid lift,1.5 dB HF lift and 1.5 dB combination |
| INPUTS | RCA unbalanced |
| INPUT IMPEDANCE | Unbalanced 47 kOhm |
| FREQUENCY RESPONSE | Less than +/- 0.1 dB deviation 20 Hz - 20 kHz |
| PHASE RESPONSE | Less than 2 degrees deviation 20 Hz - 20 kHz |
| SIGNAL TO NOISE RATIO | More than 110 dB |
| DISTORTION | Less than 0.05% at rated power 8 ohms load |
| INTERMODULATION | Less than 0.05% (19 kHz + 20 kHz) |
| DAMPING FACTOR | More than 500 |
| POWER SUPPLY | 700 VA; 65,800 uF capacitors |
| OUTPUT STAGE | 2 Pair of 15A 150W, Sanken Audio grade, High bandwidth, ultra-low distortion matched complementary transistors /per channel |
| POWER CONSUMPTION | 40 W in standby switched on |
| ADDITIONAL FEATURES | Speaker soft start & shutdown, short circuit, dc and thermal protection, 3 RCA Line IN I/P |
| HEIGHT (Including rubber feet) | 5.9’’ (15 cm) |
| WIDTH | 17” (43.18 cm) |
| DEPTH | 15.5” (39.37 cm) |
| WEIGHT | 15 Kg (33 lbs) |
DISCLAIMER : All products, product specifications and data are subject to change to improve reliability, function or design, without notice
