Just as SAPTAK signifies the entire Indian classical music scale, our amplifiers are designed for accurate and perfect reproduction of the entire music scale.
Dual Mono Stereo Power Amplifier (Platinum)
Dual Mono Stereo Power Amplifier
- Dual Mono
- 1.5 dB dynamic head room
- Extremely low distortion levels
- Anodized & Minimalistic front panel
- Natural, rhythmic and dynamic sound
- Anodized exposed heat sinks to eliminate cooling fan
| General Description | Dual Mono Stereo Power Amplifier |
|---|---|
| OUTPUT POWER | 195 watts @ 8 Ohms per channel |
| POWER AMPLIFIER CLASSIFICATION | Class AB |
| INPUTS | RCA unbalanced |
| INPUT IMPEDANCE | Unbalanced 25 kOhm |
| FREQUENCY RESPONSE | Less than +/- 0.2 dB deviation 10 Hz - 20 kHz |
| PHASE RESPONSE | Less than 2 degrees deviation 10 Hz - 20 kHz |
| SIGNAL TO NOISE RATIO | More than 110 dB |
| DISTORTION | Less than 0.05% at rated power 8 ohms load |
| INTERMODULATION | Less than 0.01% (19 kHz + 20 kHz) |
| DAMPING FACTOR | More than 500 |
| POWER SUPPLY | 530 + 530 VA dual mono; 40,000 + 40,000 uF capacitors |
| OUTPUT STAGE | 20 pcs 15 A 150 W high speed, ultra-low distortion bipolar transistors |
| POWER CONSUMPTION | 60 W in standby switched on |
| ADDITIONAL FEATURES | Speaker soft start & shutdown, short circuit, dc and thermal protection |
| HEIGHT (Including rubber feet) | 6.9’’ (17.5 cm) |
| WIDTH | 17.5” (44.5 cm) |
| DEPTH | 17” (43.18 cm) |
| WEIGHT | 25 Kg (55.1 lbs) |
DISCLAIMER : All products, product specifications and data are subject to change to improve reliability, function or design, without notice
